17m Ferry

catamaran 15
catamaran 15

BASIC INFO

Type Passenger Ferry
Material Aluminium

PRINCIPAL PARTICULARS

Length Overall 17.07m
Length Waterline 16.38m
Load Line Length 17.07m
Moulded Beam 6.50m
Maximum Draught 1.17m

CAPACITIES

Fuel Oil 1,500 litres
Fresh Water 300 litres
Black Water 250 litres
Crew 2 persons Additional seating for 60 PAX

MACHINERY

Main Engines 2 x 464HP Yanmar
Propulsion 2 x 4 Blade FPP (waterjets available)

PERFORMANCE

Max. Speed 26.0 kts
Service Speed 18.0 kts

This is a design specifical ly for carrying passengers, either as a pure harbour type ferry boat or as a higher end tourism excursion vessel.

Sheltered and inside seating for 60 passengers and up to 80 passengers for fine weather which allows the upper deck to come into play.

Surveyed primarily for sheltered water use, the design can be easily up graded more exposed coastal conditions. The efficient and sea worthy displacement hull form gives the optimum comfort for the passengers and the minimum fuel cost for the operator.

Seating can be reconfigured easily for alternative corporate entertaining with on board dining, conference work, etc.Top speed is 26 knots, general operating speed is 18 knots.
